Proven Performance
Integrated noise barriers for modern infrastructure. Structurally sound, visually refined, and ready for specification.
Integrated noise barriers for modern infrastructure. Structurally sound, visually refined, and ready for specification.
Coverage: 25-year warranty on SilentVue™ acrylic noise barrier panels.
Performance Guarantee:
- Maintain structural integrity, tensile strength, rigidity, and optical clarity.
- Resist UV degradation, yellowing, and light loss (within standards).
- Stay compliant with Australian noise wall specifications: TfNSW R271, QLD MRTS15, WA TS 03247.
Standards Met:
Acoustic: EN 1793-2 (sound insulation)
Structural: EN 1794-1/2 (safety & impact resistance)
Optical: DIN 5036, ISO 4892-2 (light transmission & UV stability)
Conditions: Warranty valid only with correct installation/maintenance; excludes damage from misuse, chemical exposure, or impacts beyond tested limits.
Product Overview:
Transparent or tinted acrylic noise barrier system for highways, urban areas, commercial, and industrial projects. Designed for durability, low maintenance, and a 25-year service life.
Materials & Construction:
Premium acrylic or laminated composite panels. Anti-UV coating for colour stability. Optional acoustic absorptive backing. Stainless steel/corrosion-resistant fixing systems.
Performance:
Acoustic reduction: 20–30 dB (config-dependent). Transmission loss: Up to 30 dB. Wind load resistance: Up to 2 kPa. Fire rating: AS/NZS compliant.
Testing Standards:
Density: 1.20 g/cm³ (ISO 1183). Tensile strength: 70 MPa (ISO 527). Light transmittance ≥90% (ASTM D1003). Impact resistance: EN 12600 Class A. Noise reduction index: 29–35 dB (BS EN 1793-2).
Design Considerations:
Modular, customisable, available in clear, frosted, or coloured options. Maintains sightlines while reducing noise.
Installation:
Panels clamped and aligned on posts/walls. Post-installation inspection required.
Cleaning & Maintenance:
Mild detergent, soft cloths. Approved solvents for stains (hexane, kerosene, isopropyl alcohol).
Storage:
Panels are shipped with protective masking (PE or paper) to avoid moisture/dust. Store vertically at ~10° or horizontally on a flat surface.
Masking Removal:
Keep masking on until installation. Remove carefully to avoid scratching or entanglement.
Cleaning:
Use microfiber cloth and mild soapy water. For stains: hexane, kerosene, aliphatic naphtha (check compatibility).Avoid dry cloths (causes scratches and static).
Graffiti Removal:
Use organic adhesive removers where possible. Apply, leave for 2–3 minutes, rinse thoroughly.
Polishing:
Use approved scratch removers (e.g., NOVUS 2, PlastX).
Static Charge Control:
Prevent static build-up with ionising air guns or anti-static treatments.
Material Compatibility:
Avoid incompatible chemicals (certain cleaners, adhesives, sealants) that may cause crazing or cracking.
Protective Masking Marking:
Paper masking can be marked with pens/pencils.PE masking only with approved industry markers.
